The Industry’s Highest Resolution for CAD
Specifically designed for architectural, engineering, construction, mechanical design and GIS applications, Drafstation series plotters can help you put your best foot forward. Offering a maximum media width of 42" and 24", Drafstation series plotters give you high-quality professional printers at an exceptional price point.
Draft Station Features
Intelligent Interweave
Intelligent Interweave offers many printing effects to improve the image quality. MUTOH further enhances the original print effects, and they allow the reduction and elimination of the banding that is the primary weakness of Ink jet printing, creating a fine tuned balance between print speed and quality.
ValueJet Status Monitor
Let Your Printer Do the Work for You! The ValueJet Status Monitor is light-weight software exclusive to MUTOH. It offers remote control and monitoring for your MUTOH printers via Wireless LAN on your portable smart devices. The ValueJet Status Monitor maximizes the performance of the MUTOH printer and makes your workflow easy. It also utilizes MUTOH’s ColorVerify process control system to monitor your color output for consistent color production print after print.
Print head
4 separate print heads existed previously are combined together to form 1 print head. The printer is runnning in 4 colors, and no adjustment in between the colors are required. That is why the beautiful output can be esily achieved.
Variable Dot Technology
By adopting the high quality print head, it incorporates 3 kinds of variable dot which are large, medium and small diameter so as to realize high quality, standard quality, and high speed printing.
Pressure Roller Canceller
Pressure Roller Canceller is specially developed to feed the thin tracing paper.
Specifications
| Model Name | RJ-900X | |
|---|---|---|
| Printer Technology | Drop-on-demand Micro Piezo Inkjet Technology | |
| Print Head Nozzle Configuration | 180 nozzles x 8 lines | |
| Print Head Height Adjustment | 1.2mm / 2.0mm | |
| Ink Cartridge | Ink Types | MUTOH Drafstation water based-pigment ink (K) / MUTOH Drafstation water based-dye ink (C, M, Y) |
| Ink Color | 4 colors (C,M,Y,K) | |
| Capacity | 110ml Cartridge (±5%) | |
| Maximum Media Width | 1,080mm | |
| Minimum Media Width | 150mm | |
| Media Thickness | Print Head Height Low: 0.3mm / High: 1.3mm | |
| Maximum Roll Media Weight & Media Core Diameter | 19kg / φ150mm / 2 inches ( 3 inches: option) | |
| Maximum Print Width | 1,074mm | |
| Print Margin | Rigid | 3mm (Front) / 17mm (Back) / 3mm (Left / Right) |
| Roll | 3mm (Front) / 3mm (Back) / 3mm (Left / Right) | |
| Print Resolutions | 360dp/720dpi/1440dpi/2880dpi | |
| Maximum Production Speed(*1) | 33s | |
| Interface | Ethernet 100BASE-TX/10BASE-T | |
| Printer Language | MH-GL, MH-GL/2, MH-RTL, RTL-PASS | |
| Memory | 256MB | |
| Power Supply | AC100-240±10%（50/60Hz) | |
| Power Consumption | Power OFF | 1W |
| Operation | 100W | |
| A-property Acoustic Power Level (Actual Measured Value) | Approx.65.1dB | |
| Operating Environment | Temperature 10～35℃ / Humidity 40～60% (Non Condensing) | |
| Certification | MET(USA), CE(EU), FCC(USA), VCCI(Japan), RoHS(EU), CB REPORT | |
| Machine Mesurements | (W)1,772 mm x (D)662mm x (H)978 mm (Printer with Stand) | |
| Printer Weight | Printer | 49.5kg |
| Stand | 15.5kg | |
| Packing Size | Printer | (W)1,905 mm x (D)630 mm x (H)581 mm / 69kg |
| Stand | (W)1,510 mm x (D)435 mm x (H)260 mm / 21kg | |
| Option | A0 Scroller 2 Inches RJ9-SR02 | |
| Flange Spacer 3 inches Assy RJ9-FS03 | ||
| Media Holder RJ9-PH | ||
| Stand (A0) RJ900X-STD | ||
| Stand (A0_HIGH) RJ900X-STD-HIGH | ||
| Wast Paper Basket (A0) RJ900X-BSKT-A0 | ||
